H2150A is a new type of smart face-paying intelligent ordering machine with HUARUI intelligent customization. It adopts Android operating system, quad-core CPU, stable performance, supports advertising interaction, NFC payment, QR code scanning payment, thermal printing ticket and other functions. . Also equipped with a camera for facial recognition / face payment.
Key
Features
1, industrial-grade motherboard design, Android RK3288/RK3568,Windows J1900/I3/I5/I7.
2, Android 8.1/11 Or Windows 7/8/10/11 operating system optional.
3, 21.5-inch capacitive touch screen, touch sensitive, no drift, resolution 1920*1080.
4, support NFC payment / two-dimensional code payment, thermal printing ticket and other functions.
5, with a camera, support for face recognition, support for external red induction.
6, support vertical or wall hanging.
Specifications
| H2150A Android/Windows 21.5 inch Self-Service Kiosk Machine | |
| CPU | Android RK3288/RK3568,Windows J1900/I3/I5/I7 |
| System language | Android 8.1/11 Or Windows 7/8/10/11 |
| RAM ROM | Android 2+16GB (4+64 MAX) or Windows 4+32 (MAX 8+512GB SSD) |
| Display | 21.5 inch TFT IPS with resolution 1080*1920 (24 inch optional) |
| Touch screen | 21.5 inch Taiwan true flat capacitive screen. Support 10 point touch (24 inch optional) |
| Network communication | Wired Ethernet RJ45 WIFI Bluetooth 4.0 |
| Audio | Left and right dual channel 8R*5W |
| I/O interface | 1 * DC |
| 1 * VAG interface | |
| 4 * USB-host (3 USB2.0 1 OTG) | |
| 1 * Ethernet port (RJ45) | |
| 1 * Serial port | |
| 1 * 3.5mm Audio port | |
| Floor Standing(Optional) | 1.2 meter stand optional, wall mounted by default |
| NFC Reader | 13.56MHZ ISO/IEC 14443 TYPE A/B. Mifare card read and write |
| Barcode scanner | 2D：PDF417, QR Code (QR1/2, Micro), Data Matrix (ECC200, ECC000, 050, 080, 100, 140), 1D：Code128,UCC/EAN-128, AIM-128,EAN-8,EAN-13, ISBN/ISSN, UPC-E, UPC-A, Interleaved 2 of 5, ITF-6, ITF-14,Matrix 2 of 5, Industrial 25, Standard 25, Code39,Codabar, code93, Code 11,Plessey, MSI-Plessey, GS1- DataBar (RSS), (RSS-14, RSS- Limited,RSS-Expand) |
| Recognition accuracy | ≥ 5 mil |
| Interface mode | USB |
| Beep | Buzzer |
| In-built printer | 80mm auto cutter printer |
| Print resolution | 203*203DPI |
| Printing speed | 150mm/s(max) |
| Printer life | 100KM 1 million times |
| Operating temperature | Temperature: 0°C-55°C; equivalent humidity: 20%-90% |
| Net weight | Net weight: 16kg Gross weight 19.5KG |
| Dimensions | (W) 385mm* (High) 830mm* (Thick) 50-110mm |
| Carton size | (W) 450mm* (H) 900mm* (Thick) 160mm |
| Optional functions | Base stand Induction card reader RFID 3G/4G module WeChat / Alipay brush face payment 3D camera Flat camera MIC |
Applications
